The safe one for large amounts of pure water.
For H2O pure CLRW (CLSI) + DIN EN 285 + EN ISO 15883.
If safety is paramount and the quality of the cleaning already determines the quality of the results, then the OmniaLabDS system is the perfect solution.
Even for large pure water volumes up to 60 l, the OmniaLabDS guarantees compliance with international water standards in laboratories and medical technology. The combination with regenerative polisher cartridges and an optional emergency supply makes the system predestined for the reliable supply of clinical analyzers. For the supply of steam sterilizers as well as for cleaning and disinfecting devices.
- OptiFill dispenser with LCD display as standard
- Tank volume display in percent
- 100 l tank with recirculation and pressure outlet
- Tank volume modularly expandable
- spent filters are simply and quickly exchanged
- Leakage sensor as standard
- optionally with emergency supply module
- optionally with degassing unit
- One-handed operation
- Convenient water withdrawal
- Flexible on the work surface
- Tank space-saving under the work surface
| OmniaLabDS 20 | OmniaLabDS 40 | OmniaLabDS 60 | |
|---|---|---|---|
| Pure water Typ II + CLRW (CLSI) DIN EN 285 + ISO EN 15883 |
|||
| Pure water performance at 15 °C [l/h] | 20 | 40 | 60 |
| Conductivity at 25 °C [µS/cm] | 0.1 up to 1 | 0.1 up to 1 | 0.1 up to 1 |
| Resistance at 25 °C [MΩ x cm] | 10 up to 1 | 10 up to 1 | 10 up to 1 |
| Dispensing performance dispenser [l/min.] | up to 2 | up to 2 | up to 2 |
| Particles* > 0.2 µm [1/ml] | < 1 | < 1 | < 1 |
| Bacteria* [KBE/ml] | < 0.1 | < 0.1 | < 0.1 |
| Pure water tank pressurized outlet | optional | optional | optional |
| OmniaLabDS 20 | OmniaLabDS 40 | OmniaLabDS 60 | |
|---|---|---|---|
| Softened or hardness-stabilized water according to DIN 2000 | |||
| Feedwater temperature [°C] | + 2 up to 35 | + 2 up to 35 | + 2 up to 35 |
| Manganese and iron content [mg/l] | < 0.05 | < 0.05 | < 0.05 |
| Free chlorine content [mg/l] | < 0.1 | < 0.1 | < 0.1 |
| Silt density index (SDI) | max. 3 | max. 3 | max. 3 |
| OmniaLabDS 20 | OmniaLabDS 40 | OmniaLabDS 60 | |
|---|---|---|---|
| Connector size | R3/4″ | R3/4″ | R3/4″ |
| Operating pressure [bar] | 2 up to 6 | 2 up to 6 | 2 up to 6 |
| Supply voltage [Volt/Hz] | 90-240/50-60 | 90-240/50-60 | 90-240/50-60 |
| Connected load [kW] | 0.1 | 0.1 | 0.1 |
| Ambient temperature [°C] | + 2 up to 35 | + 2 up to 35 | + 2 up to 35 |
| Dimensions tower* [W x H x D mm] | 511 x 1520 x 575 | 511 x 1520 x 575 | 511 x 1520 x 575 |
| Dimensions base cabinet tank [W x H x D mm] | 511 x 800 x 575 | 511 x 800 x 575 | 511 x 800 x 575 |
| Weight (without polishing cartridge) [kg] | 39 | 39 | 40 |
| * with OptiFill Dispenser | |||
| Article no. | System type* | Typical applications |
|---|---|---|
| 18800020 | OmniaLabDS 20 | Feedwater for analyzers, autoclaves and laboratory washers |
| 18800040 | OmniaLabDS 40 | Feedwater for analyzers, autoclaves and laboratory washers |
| 18800060 | OmniaLabDS 60 | Feedwater for analyzers, autoclaves and laboratory washers |
| * RO cartridge, stainless steel polishing cartridge, sterile filter capsule 0.2 μm, sterile overflow and sterile vent filter + CO2 absorber included | ||
| Accessories | |
|---|---|
| 19200020 | Pre-treatment unit OmniaLab – 10“ |
| 19200050 | UV tank disinfection unit 254 nm |
| 19200051 | UV Flow through disinfection 254 nm |
| 12280050 | Replacement/second polishing cartridge type DS 2800 RV |
| 19200040 | Emergency supplyl |
| 19200041 | Degassing unit |
| 16561201 | External pressure booster pump SC 3000 |
Description
The safe one for large amounts of pure water.
For H2O pure CLRW (CLSI) + DIN EN 285 + EN ISO 15883.
If safety is paramount and the quality of the cleaning already determines the quality of the results, then the OmniaLabDS system is the perfect solution.
Even for large pure water volumes up to 60 l, the OmniaLabDS guarantees compliance with international water standards in laboratories and medical technology. The combination with regenerative polisher cartridges and an optional emergency supply makes the system predestined for the reliable supply of clinical analyzers. For the supply of steam sterilizers as well as for cleaning and disinfecting devices.
