Biotage® Initiator+Fourth Generation Microwave Synthesizer
Bs. 0.00Bs. 0.00
Biotage® Initiator+
Fourth Generation Microwave Synthesizer
Benefits
Biotage® Initiator+ represents a new generation of synthesizer instruments for organic, medicinal, materials, nano and polymer chemistry professionals. It is an upgradeable and reliable platform allowing chemists to make great discoveries in less time.
Your Chemistry. Simpler.
Heating reactions to high temperatures and pressures of up to 300 °C and 30 bar opens new possibilities in chemical synthesis. Now there is ultimate flexibility in choosing a solvent: even low boiling point solvents can now be run at higher temperatures. Using “Regulate on pressure” enables the reaction to reach highest possible temperature during the run. A simpler process for delivering your chemistry.
Your Chemistry. Faster.
Most chemical reactions require heating, and typically can take several hours to complete. This is a major bottleneck to chemical synthesis. However, it doesn’t have to be like this. The Biotage Initiator+ microwave system allows reactions to be completed in a fraction of the time – so an average reaction that usually takes hours is over in minutes. How does it do this? By super-heating the reaction under pressure to greater than the solvent boiling point, driving reactions to completion in record time. Your chemistry, faster.
Specifications
System Requirements
-
Location:
A laboratory fume hood with the capacity to handle leakage of solvents and provide suitable airflow to prevent the build-up of flammable vapors. -
Ambient Temperature:
Operating Temperature: 18–32 °C
Storage and transportation temperature: -25 °C to 60 °C -
Humidity:
20–95% RH (non-condensing) -
Electrical Supply:
100–120, 220–240 VAC, 50/60 Hz
Connect only to a grounded outlet -
Max Power Consumed:
1100 VA -
Cooling:
Pressurized air supply: >60 L/min (2.1 cubic feet/min), 2.5–4.0 bar (0.25–0.40 MPa; 36–58 psi) -
Weight:
21 kg (48.5 lbs) -
Dimensions (W x D x H):
365 x 422 x 421 mm (14.4″ x 16.6″ x 16.6″) -
Max Sound Level:
70 dB(A) -
Ports:
Ethernet LAN port (IEEE 802.3 compliant)
USB port (USB 3.0 compliant) -
Interfaces:
On-board computer with 10.4” diagonal touch screen
Archiving/back-up via USB
Printing via LAN -
Certification:
CE, CSA certified
Heating Process
-
Temperature Range:
40–300 °C -
Temperature Increase Rate:
Typically 2–5 °C/sec depending on solvent and power applied -
Reaction Time:
Up to 96 hours (most reactions require 2–15 minutes of irradiation) -
Pressure Range:
0–30 bar (3 MPa; 435 psi) -
Power Range:
0–400 W from magnetron at 2.45 GHz -
Reaction Volumes:
0.2–20 mL -
Agitation:
Variable magnetic stirrer (300–900 RPM)
Sample Processor
-
Upgradable with: Robot Eight / Robot Sixty
-
Processing Capacity:
8 vials / 60 vials -
Rack Capacity (Large):
2 x 2 vials / 2 x 12 vials -
Rack Capacity (Small):
2 x 4 vials / 2 x 30 vials
Description
Biotage® Initiator+
Fourth Generation Microwave Synthesizer
Biotage® Initiator+ represents the latest in microwave synthesis performance. This instrument’s high-end specifications enable the chemist to explore new areas and perform the latest of innovations in chemistry. A reliable and upgradeable platform that allows chemists to make great discoveries in less time.
