OmniaLab UP
Bs. 0.00Bs. 0.00
The reliable one for pure water.
For H2O pure type II.
If high-quality pure water is required for the complete laboratory supply, the OmniaLabUP is the right system. It meets international water standards such as ASTM, ISO 3696 and CLRW (CLSI).
In addition, the OmniaLabUP-System holds 100 liters of pure water type II in a storage tank with quality recirculation ready for withdrawal. OmniaLabUP supplies autoclaves, laboratory dishwashers and ultrapure water systems.
- OptiFill dispenser with LCD display as standard
- Tank volume display in percent
- 100 l tank with recirculation and pressure outlet
- Tank volume modularly expandable
- simple and economical filter change
- Leakage sensor as standard
- One-handed operation
- Convenient water withdrawal
- Flexible on the work surface
- Tank space-saving under the work surface
| OmniaLabUP 20 | OmniaLabUP 40 | |
|---|---|---|
| Pure water values type II | ||
| Pure water performance at 15 °C [l/h] | 20 | 40 |
| Conductivity at 25 °C [µS/cm] | 0.067 up to 0.1 | 0.067 up to 0.1 |
| Resistance at 25 °C [MΩ x cm] | 15 up to10 | 15 bis 10 |
| Dispensing performance dispenser [l/min.] | up to 2 | up to 2 |
| Particles* > 0,2 µm [1/ml] | < 1 | < 1 |
| Bacteria* [KBE/ml] | < 0.1 | < 0.1 |
| Pure water tank pressurized outlet | optional | optional |
| * with sterilizing filter 0.2 μm | ||
| OmniaLabUP 20 | OmniaLabUP 40 | |
|---|---|---|
| Softened or hardness-stabilized water according to DIN 2000 | ||
| Feedwater temperature [°C] | + 2 up to 35 | + 2 up to 35 |
| Manganese and iron content [mg/l] | < 0.05 | < 0.05 |
| Free chlorine content [mg/l] | < 0.1 | < 0.1 |
| Silt density index (SDI) | max. 3 | max. 3 |
| OmniaLabUP 20 | OmniaLabUP 40 | |
|---|---|---|
| Connector size | R3/4″ | R3/4″ |
| Operating pressure [bar] | 2 up to 6 | 2 up to 6 |
| Supply voltage [Volt/Hz] | 90-240/50-60 | 90-240/50-60 |
| Connected load [kW] | 0.1 | 0.1 |
| Ambient temperature [°C] | + 2 up to 35 | + 2 up to 35 |
| Dimensions tower* [W x H x D mm] | 511 x 1520 x 575 | 511 x 1520 x 575 |
| Dimensions base cabinet tank [W x H x D mm] | 511 x 800 x 575 | 511 x 800 x 575 |
| Weight [kg] | 40 | 40 |
| * with OptiFill dispenser | ||
| Article no. | System type* | Typical applications |
|---|---|---|
| 18600020 | OmniaLabUP 20 | Feedwater for autoclaves, laboratory washers and ultrapure water systems |
| 18600040 | OmniaLabUP 40 | Feedwater for autoclaves, laboratory washers and ultrapure water systems |
| * RO cartridge, pure water cartridge, sterile filter capsule 0.2 μm, sterile overflow and sterile vent filter + CO2 absorber included. |
||
| Accessories | |
|---|---|
| 19200020 | Pre-treatment unit OmniaLab – 10“ |
| 19200050 | UV tank disinfection unit 254 nm |
| 19200051 | UV Flow through disinfection 254 nm |
| 16561201 | External pressure booster pump SC 3000 |
