OmniaPure xs touch
Bs. 0.00Bs. 0.00
The intuitive ultrapure water specialist
For H2O pure type I.
NEW! The area-efficient, intelligent ultrapure water system with intuitive touch screen.
The Type I specialist when the highest degree of purity is required, with a resistivity of 18.2 MΩ x cm and a low TOC value of < 10 ppb. Optionally, endotoxins, nucleases and proteases are also removed.
Equipped with the new touch dispenser with modern swipe and scroll functions, the new, compact OmniaPure xstouch system offers all conceivable comfort features.
Well thought out sustainably with resource-saving Blueline features.
- very space-saving, fits on an A4 sheet
- OptiFill Dispenser with touch screen as standard
- Real-time TOC monitoring
- Precise volume control
- resource-saving filter volume with residual filter display
- USB interface
- Leakage sensor as standard
- integrated pressure reducer as standard
- Easy filter change
- ready-to-use, ready for connection incl. filter inserts
- One-handed operation
- Convenient water withdrawal
- Space-saving on the wall
- Only dispenser on the work surface, production unit under table
- Only dispenser on the wall, production unit under table
| OmniaPure xstouch UV-TOC | OmniaPure xstouch UV-TOC/UF | |
|---|---|---|
| Ultrapure water values type I | ||
| Conductivity at 25 °C [µS/cm] | 0.055 | 0.055 |
| Resistance at 25 °C [MΩ x cm] | 18.2 | 18.2 |
| TOC-value* [ppb] | < 2 | < 5 |
| TOC monitor | ja | ja |
| Dispensing performance [l/min.] | up to 2 | up to 2 |
| Individually adjustable dispensing volume [litres] | 0.05 up to 25 | 0.05 up to 25 |
| Particles** > 0.2 µm [1/ml] | < 1 | < 1 |
| Bacteria** [KBE/ml] | < 0.01 | < 0.01 |
| Pyrogens (Endotoxins)*** [EU/ml] | – | < 0.001 |
| RNase*** [pg/ml] | – | < 1 |
| DNase*** [pg/ml] | – | < 5 |
| Proteases*** [µg/ml] | – | < 0.15 |
| * The values given are typical and may vary depending on the quality of the feed water |
** With sterile filter capsule 0.2 μm or bio filter capsule | *** With ultrafilter/bio filter capsule |
| OmniaPure xstouch UV-TOC | OmniaPure xstouch UV-TOC/UF | |
|---|---|---|
| Water prepared by ion exchange, reverse osmosis, electrodionisation or distillation | ||
| Feedwater pressure [bar] | 0.5 up to 6 | 0.5 up to 6 |
| Feedwater temperature [°C] | + 2 up to 35 | + 2 up to 35 |
| Conductivity at 25 °C [µS/cm] | < 100 | < 100 |
| TOC-value [ppb] | < 50 | < 50 |
| OmniaPure xstouch UV-TOC | OmniaPure xstouch UV-TOC/UF | |
|---|---|---|
| Feedwater connection | R3/4″ | R3/4″ |
| Electrical connection [Volt/Hz] | 90 – 240/50 – 60 | 90 – 240/50 – 60 |
| Connected load [W] | 120 | 120 |
| Ambient temperature [°C] | + 2 up to 35 | + 2 up to 35 |
| Printer port | RS232 | RS232 |
| Data port | USB-A | USB-A |
| Dimensions* [W x H x D mm] | 240 x 530 x 435 | 240 x 530 x 435 |
| Weight dry* [kg] | 14 | 14 |
| Dimensions production unit under table [W x H x D mm] | 240 x 415 x 310 | 240 x 415 x 310 |
| Weight production unit dry [kg] | 13 | 13 |
| Dimensions OptiFill touch wall dispenser [W x H x D mm] | 100 x 520 x 460 | 100 x 520 x 460 |
| Weight wall dispenser [kg] | 2.4 | 2.4 |
| Dimensions OptiFill touch bench dispenser [W x H x D mm] | 150 x 580 x 450 | 150 x 580 x 450 |
| Weight bench dispenser [kg] | 8 | 8 |
| * With OptiFill touch dispenser |
| Article no. | System type* Standard |
Article no. | System type Production unit + wall dispenser*/** |
Article no. | System type Production unit + bench dispenser*/** |
Typical applications |
|---|---|---|---|---|---|---|
| 18100004 | OmniaPure xs UV-TOC | 18100014 | OmniaPure-W xs UV-TOC | 18100024 | OmniaPure-T xs UV-TOC | Ultra-trace analysis, ICP-MS, HPLC, TOC-analysis |
| 18100005 | OmniaPure xs UV-TOC/UF | 18100015 | OmniaPure-W xs UV-TOC/UF | 18100025 | OmniaPure-T xs UV-TOC/UF | Life science and microbiology, cell culture media |
| * Pre-treatment cartridge-, ultrapure water cartridge and steril filter capsule 0.2 μm included | ** The Omnia xs production unit can either be installed on a bench, on a wall or under the bench. | |||||
| Accessories | |
|---|---|
| 19200305 | Wall mount Omnia xs |
| 19200090 | Disinfection cartridge Omnia xs |
| 19200057 | Disinfectant Omnia – 3 pcs. / pack |
| 19200091 | Disinfection kit Omnia xs complete |
| 19102100 | Bio filter capsule |
Description
The intuitive ultrapure water specialist
For H2O pure type I.
NEW! The area-efficient, intelligent ultrapure water system with intuitive touch screen.
The Type I specialist when the highest degree of purity is required, with a resistivity of 18.2 MΩ x cm and a low TOC value of < 10 ppb. Optionally, endotoxins, nucleases and proteases are also removed.
Equipped with the new touch dispenser with modern swipe and scroll functions, the new, compact OmniaPure xstouch system offers all conceivable comfort features.
Well thought out sustainably with resource-saving Blueline features.
