OmniaLab RO

Bs. 0.00Bs. 0.00

The powerful for constantly large quantities of pure water.
For H2O pure type III.

If there is a need for constantly large quantities of reverse osmosis water in the laboratory, the OmniaLabRO is used. The system meets the international water standard type III.

In addition, the OmniaLabRO system holds 100 liters of reverse osmosis water in a storage tank ready for withdrawal. This system is used to supply autoclaves, laboratory dishwashers, humidifiers, and ultrapure water systems.

  • OptiFill dispenser as standard
    • Tank volume display in percent
  • with 100 l pure water tank
  • Tank volume modularly expandable
  • Leakage sensor is standard

OmniaLabRO 20 OmniaLabRO 40 OmniaLabRO 60
Reverse osmosis water type III
Pure water performance at 15 °C [l/h] 20 40 60
RO membrane retention rate for ions, germs and bacteria [%] > 98 > 98 > 98

OmniaLabRO 20 OmniaLabRO 40 OmniaLabRO 60
Softened or hardness-stabilized water according to DIN 2000
Feedwater temperature [°C] + 2 up to 35 + 2 up to 35 + 2 up to 35
Manganese and iron content [mg/l] < 0.05 < 0.05 < 0.05
Free chlorine content [mg/l] < 0.1 < 0.1 < 0.1
Silt density index (SDI) max. 3 max. 3 max. 3

OmniaLabRO 20 OmniaLabRO 40 OmniaLabRO 60
Connector size R3/4″ R3/4″ R3/4″
Operating pressure [bar] 2 up to 6 2 up to 6 2 up to 6
Supply voltage [Volt/Hz] 90-240/50-60 90-240/50-60 90-240/50-60
Connected load [kW] 0.1 0.1 0.1
Ambient temperature [°C] + 2 up to 35 + 2 up to 35 + 2 up to 35
Dimensions tower* [W x H x D mm] 511 x 1520 x 575 511 x 1520 x 575 511 x 1520 x 575
Dimensions base cabinet tank [W x H x D mm] 511 x 800 x 575 511 x 800 x 575 511 x 800 x 575
Weight [kg] 38 38 40
* with OptiFill Dispenser

Article no. System type* Typical applications
18500020 OmniaLabRO 20 Feedwater for autoclaves and laboratory washers, ultrapure water systems and air humidifiers
18500040 OmniaLabRO 40 Feedwater for autoclaves and laboratory washers, ultrapure water systems and air humidifiers
18500060 OmniaLabRO 60 Feedwater for autoclaves and laboratory washers, ultrapure water systems and air humidifiers

Accessories
19200020 Pre-treatment unit OmniaLab – 10“
19200050 UV tank disinfection unit 254 nm
16561201 External pressure booster pump SC 3000

Description

The powerful for constantly large quantities of pure water.
For H2O pure type III.

If there is a need for constantly large quantities of reverse osmosis water in the laboratory, the OmniaLabRO is used. The system meets the international water standard type III.

In addition, the OmniaLabRO system holds 100 liters of reverse osmosis water in a storage tank ready for withdrawal. This system is used to supply autoclaves, laboratory dishwashers, humidifiers, and ultrapure water systems.
